Beschrijving

FRAMESpark Alloy SL 6011
Integrated Suspension Technology
Flex Pivot / Adjustable head angle
Syncros Cable Integration System
BB92 / UDH Interface / 12x148mm with 55mm Chainline
FORKRockShox Judy Silver TK Solo Air
15x110mm QR axle / 42mm offset / Tapered Steerer
2-Modes / Reb. Adj. / Lockout / 130mm travel
REAR SHOCKX-Fusion NUDE 5 RLX Trunnion
SCOTT custom w. travel / geo adj.
3 modes: Lockout-Traction Control-Descend
Reb. Adj.
Travel 120-80-Lockout / T165X45mm
REMOTE SYSTEMSCOTT TwinLoc 2 Technology
Suspension & Dropper Remote
3 Suspension modes
REAR DERAILLEURShimano XT RD-M8100 SGS
Shadow Plus / 12 Speed
SHIFTERSShimano Deore SL-M6100-R / Rapidfire Plus
CRANKSETShimano FC-MT512-1
55mm CL / 32T
BB-SETShimano BB-MT500 / shell 41x92mm
CHAINKMC X12
CASSETTEShimano Deore CS-M6100-12 / 10-51 T
BRAKESShimano MT501 Disc
ROTORShimano SM-RT54 CL / F&R 180mm
HANDLEBARSyncros Fraser 2.0 DC Alloy 6061 D.B.
mini Rise / back sweep 8° / 760mm
Syncros Pro lock-on grips
H'STEMSyncros DC 3.0
Syncros Cable Integration System
0° rise / 6061 Alloy / 31.8mm / 1 1/8″
SEATPOSTSyncros Duncan Dropper Post 2.5
31.6mm / S & M size 125mm / L & XL size 150mm
SEATSyncros Tofino 2.5 Regular
HEADSETSyncros – Acros Angle adjust & Cable Routing HS System
+-0.6° head angle adjustment
ZS56/28.6 – ZS56/40 MTB
HUB (FRONT)Shimano HB-MT410-B CL / 15x110mm
HUB (REAR)Shimano FH-MT410-B CL / 12x148mm / Micro Spline
SPOKESStainless Black 15G / 1.8mm
RIMSSyncros X-30SE / 32H / 30mm
FRONT TIRESchwalbe Wicked Will / 29×2.4″
Performance / TLR / Foldable / Addix
REAR TIRESchwalbe Wicked Will 29×2.4″
Performance / TLR / Foldable / Addix
APPROX WEIGHTS IN KG14.95 (with tubes)
